CORiTEC Aligner L Robot

- 5 axis processing (3+2 and simultaneous)
- rotation-axis 360 degrees, pivot-axis up to 115 degrees
- integrated zero point clamping system
- high dynamic AC servomotors with absolute encoder
- massive axis construction made of polymer concrete
- high performance high frequency spindle up to 60.000 rpm
- collet 6mm shaft
- automatic 20 fold tool changer
- integrated ionizer
- temperature compensation for consistent high precision
- work area with an extra large 100mm drain
- 6 axis robot for automatic loading and unloading of the machine
- tray automation with 80 magazine positions
- protective housing
- integrated 20W fiber laser with galvo scan head
- prepared interface for holding the aligners
- QR code scanner for automatic job identification
- extraction device and extra large extraction kit for maximum chip removal
- high shine chassis with LED illumination
- incl. integrated 15" touch screen and control PC
- integrated job manager application
- including CNC-control software CORiTEC Remote DENTAL 3.0
